WI-3000

Weld & Profile Geometry

Geometry Inspections

for Large Tube & Pipe

A precision laser-based 3D inspection system to detect quality issues related to forming & welding processes on larger diameter tube or pipe mills.

Making welded tube and pipe requires several key variables to be in check for efficient, stable production and to meet the increasing quality demands of the industry. Mill dynamics, from setup to production, have an impact on the stability of these variables and measurement / monitoring is the first step in controlling these variables and improving weld quality.

Xiris’s proven laser-based vision system technology with high resolution, fast data capture and analysis rates provides real-time detection of defects down to 0.030 mm in size. Defects inspected include mismatch, undercut, sunken welds, bead height, deflection, freeze line and scarfing defects.

Several models of the WI-3000 are available depending on the Field of View (FOV) requirements, type of Mill and size of the Tube/Pipe being run during the welding process.

The WI-3000 system is particularly suitable for a wide range of HF Mills making tube/pipe from OD >12 mm with bead sides up to 28mm wide. Other applications also include Longitudinal or Spiral Pipe manufacturing.

Reduce Set Up & Lab Time

Set up production equipment faster through immediate measurement feedback of process inputs. Reduce the number of required line qualifications and related micrographs to be taken of new production runs.

Reduce Mill Downtime

Reduce the time required to correct and out-of-control process; Find defects earlier on the production line with better defect detection.

Improve Customer Satisfaction

Reduce customer returns with better defect detection, ability to record defect and review offline. Detect defects other NDT equipment cannot detect.

Seeing is believing

The standard WI-3000 system is composed of an Image Acquisition Assembly (including Sensor Head, Sensor Mount/adjust assembly), an Image Processing/Display console (HMI Console with touchscreen monitor, Industrialized PC), status light tower and interface control module. The WI-3000 system is liquid cooled.


Monitor These Defects for Process Control

Mismatch

Xiris Mismatch

Freeze Line

Xiris Freeze Line

Undercut

Xiris Undercut

Roll

Xiris Roll

Bead Height

Xiris Bead Height

Slope Angle

Xiris Slope Angle

Deflection

Xiris Deflection

Bead Ratio

Xiris Bead Ratio

Resolution: 1024 x 776 pixels (HR)
Sensor Head: 180 mm (7”) (W) X 100 mm (4”) (D) x 265 mm (10.4”) (H); 4.4 Kg (9.7lb)
HMI Enclosure: Industrial enclosure with 15” Touch Screen LCD. 485 mm (19.1”) (W) X 212 mm (8.4”) (D) x 340 mm (13.4”) (H); 15.5 Kg (34lb)
GUI Languages Supported: English, German, Spanish, Portuguese, French, Dutch, Japanese, Chinese. Others on request.
Cooling Assembly (Sensor Head): Water Cooled 2 L/min
Machine Interfaces: 4 Digital Inputs and Outputs, Connection for Marking System (Encoder Inputs / Sprayer Outputs)
Cable: 10m (32.8’) standard

Universal Mount / Adjust system for easy Vertical & Horizontal set-up / OPC Interface

Powerful Weld Inspection WI Software for all set-up, measurements, alarming and data interfaces. Weld Bead Measurements Made Mismatch, Bead Height, Bead Width, Concavity, Undercut.
